Home > products > RV Camper Battery > Rechargeable BMS Lithium ion Battery 12v 100Ah 120Ah 150Ah LiFePO4 Deep Cycle Marine&RV Batteries

Rechargeable BMS Lithium ion Battery 12v 100Ah 120Ah 150Ah LiFePO4 Deep Cycle Marine&RV Batteries

Product Details

Place of Origin: China

Brand Name: LEADYO

Certification: UN38.3, CE,MSDS,UKCA

Model Number: LP12V100

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: Negotiable

Packaging Details: UN3480 Standard Export

Delivery Time: 15-45 Days

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Online

Supply Ability: 60Mwh

Get Best Price
Highlight: Deep Cycle Marine Batteries,marine Battery,lithium Marine Battery
Type:
Lifepo4 Battery Pack,lithium Ion Battery ,lithium Iron Phosphate Battery,deep Cycle Batteries
Voltage:
12.8V
Capacity:
100Ah 120Ah 150Ah
Weight:
13-16kg
Dimension((L*W*H):
330*175*210mm
Function:
Blutooth & LCD & Others(Option)
Custom:
Support
Type:
Lifepo4 Battery Pack,lithium Ion Battery ,lithium Iron Phosphate Battery,deep Cycle Batteries
Voltage:
12.8V
Capacity:
100Ah 120Ah 150Ah
Weight:
13-16kg
Dimension((L*W*H):
330*175*210mm
Function:
Blutooth & LCD & Others(Option)
Custom:
Support
Rechargeable BMS Lithium ion Battery 12v 100Ah 120Ah 150Ah LiFePO4 Deep Cycle Marine&RV Batteries

 Rechargeable BMS Lithium ion Battery 12v 100Ah 120Ah 150Ah LiFePO4 Deep Cycle Marine&RV Batteries



Lithium Iron Phosphate Battery 12V 100Ah

Nominal Voltage 12.8V

Nominal Capacity 100 Ah

Capacity @ 20A 300 min

Energy 1280 Wh

Resistance ≤30 mΩ @ 50%

SOC Self Discharge <3% / Month

Balancing function

With Smart BMS has the over charge, over discharge, over current, short circuit, Over Temperature protection and balance function.



12v 100Ah lifepo4 battery widely use in 4WD, caravan, camper van or other solar storage ect...

High performance and COMPETITIVE PRICE than market.

•12.8v 100ah

•Max continuous discharge 150A/200A

•24V&36V&48V series, no limit parallel

•Custom-made BMS for safety protection

Bluetooth App,easy to monitor battery status by Android and iOS.

•Low temperature with HEATING system

•With CE,UN38.3 and MSDS certificates

Please contact us if you are interested.



ELECTRICAL SPECIFICATIONS   MECHANICAL SPECIFICATIONS
Nominal Voltage 12.8V   Terminal Type M8
Nominal Capacity 100Ah   Weight 13kg
Nominal Energy 1280Wh   Case Dimension(L*W*H) 330*175*210mm
Internal Resistance ≤30 @50% SOC   Case Type ABS
Capacity @24A: 300minutes(5hours)   Cell type / Chemistry LiFePO4
Self Discharge 5% /per month   LCD or Bluetooth Function Optional
Maximum In Series and Parallel 4PCS   BMS:low voltage,high voltage,over temperature,
Maximum In Parallel No limit   Over current,short-circuit protection .etc
Discharge Current and Voltage Specifications   Charge Current and Voltage Specifications
MAX Continuous Discharge Current 200A   Max Charge Current 200A
Peak Current 500A   Recommended Charge Current 25A - 60A
Discharge pulse current 700±50A (31±10ms)   End of Charge voltage 14.4V±0.2V
BMS Low Voltge Cut-off 10V   End of discharge voltage 10V
Short Circuit Protection 200-800 µs Auto recover or charge release   Balancing Voltage 3.6V±0.05v pc
Temperature Ranges   COMPLIANCE SPECIFICATIONS
Discharge Temperature -20+65   Certifications CE for Battery Pack
Charge Temperature -20+45   UL1642 & IEC62133 & BIS for cells
Storage Temperature Range -20+45
BMS High Temperature Protection 90   Shipping classification UN 3480
Battery High Temperature Protection 60



Rechargeable BMS Lithium ion Battery 12v 100Ah 120Ah 150Ah LiFePO4 Deep Cycle Marine&RV Batteries 0Rechargeable BMS Lithium ion Battery 12v 100Ah 120Ah 150Ah LiFePO4 Deep Cycle Marine&RV Batteries 1







FAQ



1. Are you factory or trade company?

We ara leading battery manufacturer in China,Is a high-tech enterprise, specializing in R&D and marketing of Lithium rechargeable battery products. Our Lithium battery products are widely used in Marine boat /RV/ Camping cart/AGVGolf-cartelectric-motorcycle/Solar energy storage systemelectric vehicleselectric tools/UPS backupTelecom towersMedical equipment and etc.



2.What is your main product?
•Deep cycle LiFePo4/NMC batteries, 12V-96V LiFepo4 3-400A optional;
•Start-stop LiFepo4 12V 200CCA-1600CCA
•1-32S Lithium PCM/BMS max 250A
•NMC/LFP/LTO cells



3.When you delivery order?
Normally 7-15 days for samples order , it can be negotiated based on exact order quantity and schedule.



4.Do you accept OEM?
Yes sure, can customized your brand battery



5.May i get more golf cart lifepo4 battery?
Yes,please contact us.



6.How to get a quote?
Please contact us,sales6@leadyo-battery.com
