Brand Name: | LEADYO |
Model Number: | LP24V050 |
MOQ: | 1pcs |
Price: | Negotiable |
Packaging Details: | UN3480 Standard Export |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram,Online |
Cold weather Low Temperature high capacity lithium ion battery 24V 100Ah
Lithium Iron Phosphate Battery 25.6V 100Ah
Nominal Voltage 25.6V
Nominal Capacity 100 Ah
Capacity @ 20A 300 min
Energy 2560Wh
Resistance ≤30 mΩ @ 50%
SOC Self Discharge <3% / Month
Balancing function
With Smart BMS has the over charge, over discharge, over current, short circuit, Over Temperature protection and balance function.
What's the heating battery pack ?
LiFePO4 LT batteries have a built-in heating system featuring proprietary technology that draws power from the charger itself. No additional components are required. The heating system automatically activates once charging below -10°C is attempted, and it automatically deactivates when it’s no longer needed. the specs can customize according to your requirements
Heating specs:
1PC or 2 PC Heating foil
50W-200W (Customized)
Start heating at :-10C (can customized)
Stop heating at :0C (Can customized)
ELECTRICAL SPECIFICATIONS | MECHANICAL SPECIFICATIONS | |||
Nominal Voltage | 25.6V | Terminal Type | M8 | |
Nominal Capacity | 100Ah | Weight | 21kg | |
Nominal Energy | 2560Wh | Case Dimension(L*W*H) | 480*175*240mm | |
Internal Resistance | ≤30 @50% SOC | Case Type | ABS | |
Capacity | @20A: 300minutes(5hours) | Cell type / Chemistry | LiFePO4 | |
Self Discharge | 5% /per month | LCD or Bluetooth Function | Optional | |
Maximum In Series | 2PCS | BMS:low voltage,high voltage,over temperature, | ||
Maximum In Parallel | No limit | Over current,short-circuit protection .etc | ||
Discharge Current and Voltage Specifications | Charge Current and Voltage Specifications | |||
MAX Continuous Discharge Current | 100A | Max Charge Current | 100A | |
Peak Current | 300A | Recommended Charge Current | 14A - 25A | |
Discharge pulse current | 350±30A (31±10ms) | End of Charge voltage | 28.8V±0.4V | |
BMS Low Voltge Cut-off | 20V | End of discharge voltage | 10V | |
Short Circuit Protection | 200-800 µs Auto recover or charge release | Balancing Voltage | 3.6V±0.05v pc | |
Temperature Ranges | COMPLIANCE SPECIFICATIONS | |||
Discharge Temperature | -20~+65℃ | Certifications | CE for Battery Pack | |
Charge Temperature | -20~+45℃ | UL1642 & IEC62133 for cells | ||
Storage Temperature Range | -20~+45℃ | |||
BMS High Temperature Protection | 90℃ | Shipping classification | UN 3480 | |
Battery High Temperature Protection | 60℃ |
