| Brand Name: | LEADYO |
| Model Number: | LP48V60 |
| MOQ: | 1pcs |
| Price: | Negotiable |
| Packaging Details: | UN3480 Standard Export |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram,Online |
36 Volt Golf Cart Batteries 36V 200Ah Lithium Battery For Golf Carts
48V lithium golf cart batteries provide numerous advantages, including significant weight savings, enhanced battery chemistry for improved efficiency, a larger number of charging/discharging cycles, faster charging times, and extended range capabilities. While the initial cost of 48V lithium golf cart batteries may be higher compared to 48V lead-acid battery packs, they prove to be a cost-effective and time-saving investment in the long run. With their durability and long-lasting performance, 48V lithium batteries offer both financial and time-saving benefits that outweigh the initial price difference.
Spec of 36 Volt Golf Cart Batteries
| ELECTRICAL SPECIFICATIONS | MECHANICAL SPECIFICATIONS | |||
| Nominal Voltage | 51.2V | Terminal Type | M8 | |
| Nominal Capacity | 60Ah | Weight | 30kg | |
| Nominal Energy | 3072Wh | Case Dimension(L*W*H) | 400*198*235mm | |
| Internal Resistance | ≤30 @50% SOC | Case Type | Metal | |
| Capacity | @14A: 300minutes(5hours) | Cell type / Chemistry | LiFePO4 | |
| Self Discharge | 5% /per month | LCD or Bluetooth Function | Optional | |
| Maximum In Series | NO | BMS:low voltage,high voltage,over temperature, | ||
| Maximum In Parallel | No limit | Over current,short-circuit protection .etc | ||
| Discharge Current and Voltage Specifications | Charge Current and Voltage Specifications | |||
| MAX Continuous Discharge Current | 60A | Max Charge Current | 60A | |
| Peak Current | 150A | Recommended Charge Current | 15A - 30A | |
| Discharge pulse current | 180±30A (31±10ms) | End of Charge voltage | 57.6V±0.2V | |
| BMS Low Voltge Cut-off | 40V | End of discharge voltage | 40V | |
| Short Circuit Protection | 200-800 µs Auto recover or charge release | Balancing Voltage | 3.6V±0.05v/ cell | |
| Temperature Ranges | COMPLIANCE SPECIFICATIONS | |||
| Discharge Temperature | -20～+65℃ | Certifications | CE for Battery Pack | |
| Charge Temperature | -20～+45℃ | UL1642 & IEC62133 for cells | ||
| Storage Temperature Range | -20～+45℃ | |||
| BMS High Temperature Protection | 90℃ | Shipping classification | UN 3480 | |
| Battery High Temperature Protection | 60℃ | |||
FAQ
|
|
