Product Details
Place of Origin: China
Brand Name: LEADYO
Certification: UN38.3, CE,MSDS,UKCA
Model Number: LY4S-33
Payment & Shipping Terms
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: UN3480 Standard Export
Delivery Time: 15-45 Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,Online
Supply Ability: 60Mwh
Nominal Voltage: |
12V |
Nominal Capacity: |
33 |
Weight: |
3.5kg |
Dimension: |
Customized |
Max Charge Current: |
35A |
Max Discharge Current: |
35A |
Case: |
ABS/PVC/Epoxy |
Terminal: |
Anderson Or Others |
Smart: |
Can With RS485 |
Nominal Voltage: |
12V |
Nominal Capacity: |
33 |
Weight: |
3.5kg |
Dimension: |
Customized |
Max Charge Current: |
35A |
Max Discharge Current: |
35A |
Case: |
ABS/PVC/Epoxy |
Terminal: |
Anderson Or Others |
Smart: |
Can With RS485 |
12V 33Ah robert battery lifepo4 lithium battery with anderson connector
LEADYO Design, manufacturer and sales Custom battery for Over 15 Years.
Leadyo has been designing and assembling custom battery solutions. From medical devices, and solar power system to emergency lighting systems and many ESS applications, we can design and manufacture the perfect battery power solution for your needs.
We are industry leaders in the engineering and manufacturing of custom battery systems, with a focus on lithium battery packs. Our battery pack energy solutions optimize performance, size, working life, and cost, giving our customers a unique competitive edge.
Request a quote on custom battery packs and assemblies, or contact Leadyo to learn more.
| ELECTRICAL SPECIFICATIONS | MECHANICAL SPECIFICATIONS | |||
| Nominal Voltage |
12V |
Terminal Type | anderson or others | |
| Nominal Capacity | 33Ah | Weight | 3.5kg | |
| Nominal Energy | 396Wh | Case Dimension(L*W*H) | Custom | |
| Internal Resistance | ≤30 @50% SOC | Case Type | ABS/PVC | |
| Capacity | @7A: 300minutes(5hours) | Cell type / Chemistry | LiFePO4/NMC | |
| Self Discharge | 5% /per month | LCD or Bluetooth Function | Optional | |
| Maximum In Series | NO | BMS:low voltage,high voltage,over temperature, | ||
| Maximum In Parallel | No limit | Over current,short-circuit protection .etc | ||
| Discharge Current and Voltage Specifications | Charge Current and Voltage Specifications | |||
| MAX Continuous Discharge Current | 35A | Max Charge Current | 8A | |
| Peak Current | 80A | Recommended Charge Current | 1.5-3A | |
| Discharge pulse current | 100±10A (31±10ms) | End of Charge voltage | 28.8V | |
| BMS Low Voltge Cut-off | 10V | End of discharge voltage | 10V | |
| Short Circuit Protection | 200-800 µs Auto recover or charge release | Balancing Voltage | 3.6V±0.05v pc | |
| Temperature Ranges | COMPLIANCE SPECIFICATIONS | |||
| Discharge Temperature | -20～+65℃ | Certifications | Custom | |
| Charge Temperature | -20～+45℃ | UL1642 & IEC62133 for cells | ||
| Storage Temperature Range | -20～+45℃ | |||
| BMS High Temperature Protection | 90℃ | Shipping classification | UN 3480 | |
| Battery High Temperature Protection | 60℃ | |||
